New Holland FR600

Description

Fully serviced 2013 New Holland FR600 4WD including Kemper 375 Plus rotary corn header. 3883 engine hours, 2598 drum hours. Including kernel processor (corn cracker), automatic lubrication, spout camera, innoculant system. This machine has been serviced and repaired based on our 300 point inspection. In addition, we provide a warranty on all our machines. For more information please send us a message.

Price on request

#23098

When you enter your E-mail address, we will send you the Dekra report.

Technical specifications

Stocknumber 23098
Brand New Holland
Model FR 600
Year of manufacture 2013
Engine hours 3883
Road speed (km/h) 40
Drum hours 2598
Attr 2 or 4 wheel drive 4 WD
Engine Brand Iveco
Engine type L6
Engine Power HP 544
Engine Power (KW) 400
Front Tires Brand Trelleborg
Rear Tires Brand Michelin
Front Tires Size 800/70R38
Rear Tires Size 600/65R38
Front Tires profile 80
Rear Tires Profile 40
Emission Level Tier 3

Type knife drum Standard
Knife drum 32
Amount of knives installed 32

Kernel processor type Saw tooth

Options

Auto lubrication Yes
Automatic spout rotation Yes
Spout camera Yes
Rear view camera Yes
Rear weights Yes
Trailer hitch Yes
Innoculant system Yes
Innoculant factory installed Yes
Electrical adjustable mirrors Yes
Electrical heated mirrors Yes
Refrigurator Yes
Side window wipers Yes
Electrical KP-gap adjustment Yes
Air compressor Yes
Sunblinds window(s) Yes
Prepared for Direct Disc Yes

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Machine documents

AM Machinery inspection certificate

Image gallery

Load more images >>>

Innovation
Knowledge
Quality
Transparent

AM:Harvester Guard® Inspection Report

V = working | X* = not working, note repair recommendations | n.a. = not applicable

New
- 5
Like New
- 4
Good
- 3
Fair
- 2
Poor
- 1

Levels

Anti-freeze level in °C - 40 °C
Cooling liquid level V
Engine oil level V
Hydraulic oil level V
Left hand front end drive oil level V
Rear axle oil level V
Left hand rear end drive oil level V
Right hand rear end drive oil level V
Upper feedrolls gearbox oil level V
Gearbox oil level V
4WD gearbox oil level V
Main gearbox pump drive V
Brake fluid V

Condition Knive drum

Type knife drum Standard
Knife drum 32
Amount of knives installed 32
Knife condition 50%
Knife drum configuration Corn
Shearbar front surface 3
Shearbar rear surface 3
Shearbar active position Front
Left hand Knife drum bearing V
Right hand Knife drum bearing V
Knife drum bottom plate 5
Knife drum rear plate 5
Knife drum front cover 5
Knife drum stone cover 5
Sharpening stone 3
Left hand lift cilinder V
Right hand lift cilinder V

Kernal processor

Gras chute liner 5
Kernel processor rolls 5
Kernel processor type Saw tooth
Kernel processor front roller left hand bearing V
Kernel processor front roller right hand bearing V
Kernel processor rear roller left hand bearing V
Kernel processor rear roller right hand bearing V
Kernel processor drive belt 3
Kernel processor drive tensioner bearings V
Kernel processor drive idler roller V
Kernel processor housing 4
Tensioner springs gap adjustment V

Feedrolls

Upper front feedroll 3
Upper front feedroll wear strips 5
Upper rear feedroll 3
Metal detector roll 3
Metal detector roll wear strips 5
Smooth roll 5
Smooth roll scraper 5
Upper front feedroller left hand bearing V
Upper rear feedroller left hand bearing V
Upper rear feedroller right hand bearing V
Metal detector roll left hand bearing V
Metal detector roll right hand bearing V
Smooth roll left hand bearing V
Smooth roll right hand bearing V
Upper feedroller arm bushing V
Feeder housing wear plates 3
Upper feedrolls drive shaft V
Upper feedrolls tension springs V
Upper feedrolls arm bump stops V
Upper feedrolls gearbox V

Corn cave

Corn cave liner 5
Corn cave side liners 3
Corn cave top liner 3

Blower

Blower paddles 80%
Blower liner 3
Blower housing V
Left hand blower bearing V
Right hand blower bearing V

Transition housing

Transition housing 3
Transition liners 5

Spout

Spout turnable wear shims 3
Spout swivel tube 3
Spout complete housing 4
Spout front liner 3
Spout rear liner 3
Spout side liners 3
Inner Spout deflector 3
Outer Spout deflector 3

Engine

Dry engine V
Waterpump bearings V
Engine belting V
Engine belt tensitioners V
Exhaust system V
Engine mounting V
Airfilters V
Rotary air screen V
Rotary air screen rollers V
Cleaner cooling package V
Engine belting idler roller V

Operational test Main drive

Main clutch 3
Main drive belt 3
Main belt tensioner bearings V

Drive train

Front drive shaft's and coupler's V
Tires condition V
Rear axle drive shaft V
Rear axle stub axle V
Rear axle ball joint V
Steering cylinders V

Operators station

Front window V
Rear window V
Cab door V
Cab door latch V
Cab right hand window V
Cab roof V
Cab front bottom cover V
Mirrors V
Joystick V
Armrest control panel V
Steering wheel adjustment V
Front window wiper V
Rear window wiper blade V
Side window wipers blade V
Cab air filter V
Seat V

Machine body

Front cover V
Left hand cover V
Right hand cover V
Rear cover V

Electrical

Head lights V
Rear lights V
Brake lights V
Turn signal/hazard lights V
Rotary beacon V
Dome lights V
Cab upper front work lights V
Cab side work lights N.A.
Fender work lights N.A.
Upper rear work lights N.A.
Lower rear work lights V
Spout work lights V
Fuel gauge V

Functional test

Engine oil pressure low idle cold 5.45 Bar
Engine oil pressure high idle cold 5.95 bar
Engine oil pressure low idle operating temperature 3.4 bar
Engine oil pressure high idle operating temperature 5.6 bar
Hydrostatic drive neutral V
Transmission shifting V
4WD working (if applicable) V
Foot brakes L/R V
Parking brake V
Header Lateral Tilt (if applicable) V
Front hydraulics V
Dump valve (high flow hydraulics) N.A.
Spout turning V
Spout deflector V
Kernel processor gap adjustment V
Airconditioning cold V
Electrical functions cabin V
Camera(s) V
Radio V
Road & Working Lights V
Free of error codes V
